Lifetime

protected-cyc

Protected by built-in BMS

Line-arrow

High quality MOSFET for extended battery cell life

BMS with active energy balance system

Maintains balanced energy distribution.

Protecting the battery from overcharging, overdischarging, short circuit.

Monitoring the current state of the battery.

bms
  • Cars

  • Boats

  • Utility/Service vehicles

  • Mobile assist vehicles

Universal application

Tsapa can be used as engine stater or Energy storage unit

It is not just a new generation CAR BATTERY. it is the

ENERGY BOX

emg-img

Emergency start

Left you car light on for the night? Came back to find your car battery drained?

Use EMERGENCY START to activate the reserve charge to start your car

Modular assembly

Modular system designed for flexible combination of Tsapa Cells to cater for a wide variety of battery specifications

A = Model: LF12-040-120E-B1.2

B = Model: LF12-040-300E-B1.2

module1

Single unit

12V
40AH
(A) 120A/1.5kW
(B) 240A/3.0kW

module2

Parallel assembly

12V
80AH
(A) 240A/3.0kW
(B) 480A/6.0kW

module3

Serial assembly

24V
40AH
(A) 120A/3.0kW
(B) 240A/6.0kW

36V
40AH
(A) 120A/4.5kW
(B) 240A/9.0kW

48V
40AH
(A) 120A/6.0kW
(B) 240A/12.0kW

Note: Recommended to use 12V external TSAPA balancer in any serial assembly.
Balancer will maintain maximum usable battery capacity. Parallel assembly does not need a balancer.

module6

Serial assembly

24V
40AH
(A) 120A/3.0kW
(B) 240A/6.0kW
Note: Recommended to use 12V external TSAPA balancer

36V
40AH
(A) 120A/4.5kW
(B) 240A/9.0kW

48V
40AH
(A) 120A/6.0kW
(B) 240A/12.0kW

Note: Recommended to use 12V external TSAPA balancer

module4

Variation

24V
80AH
(A) 240A/6kW
(B) 480A/12.0kW

module5

Variation

12V
160AH
(A) 480A/12.0kW
(B) 960A/12.0kW

Note: Recommended to use 12V external TSAPA balancer

serv-icon1

Small and light
~5,5 kg

serv-icon1

Designed and made in Singapore

serv-icon1

No servicing required

serv-icon1

Safe. Utilizing the safest type of lithium cells, LiFePo4
